ATV W24
ATV W24
The ATV is a long-nosed twin tip with a Traditional Camber profile and MOD 3 Core. Double I Carbon stringers gives the ATV a familiar and responsive ride. Our Team’s All Terrain Vehicle.
139, 143, 147, 150, 151, 152.5, 155, 158, 159
Bend: Traditional Camber
Shape: Long Nose Twin
Wood Core: MOD 3
Base: Premium Racing
Tip Tech: Flexible Thin Tip
Fiberglass: Tri-Tex
Layer Strings: Double I Carbon
Edge Technology: Snake Bite Tech
Tech Specs
The ATV rides on SIMS MOD 3 Core, a combination of poplar wood native to North America and high strength to weight ratio bamboo with two parallel bamboo stringers running tip to tail under the hole pattern. Two carbon stringers, our Double I-Carbon Wide layup, run lengthwise outside the bamboo stringers. We top the ATV with our Tri-Tex fiberglass laminate, our most advanced matrix used on Sims’ top-end boards. Combined together these elements produce loads of pop and smooth rebound out of turns for all conditions ripping. A classic powerhouse construction.
Flexible Thin Tip Tech reduces material at the ends of the board for less swing weight on rotations. Snake Bite Tech 1.8 grips into the mountain with four additional contact points in the heel and toe zones, giving the rider increased edge hold and a positive state of mind in icy and hard-packed conditions. The ATV slides on SIMS Premium Racing Base, our fastest base option.
Spec (MM) |
139 |
143 |
144W |
147 |
148W |
150 |
151W |
152.5 |
154.5W |
155 |
157W |
158 |
159W |
161W |
RUNNING LENGTH |
980 |
1020 |
1060 |
1060 |
1090 |
1090 |
1120 |
1110 |
1140 |
1140 |
1150 |
1150 |
1150 |
1160 |
EFFECTIVE EDGE |
1025 |
1065 |
1105 |
1105 |
1135 |
1135 |
1165 |
1155 |
1185 |
1185 |
1195 |
1095 |
1195 |
1205 |
NOSE/TAIL WIDTH |
267 / 267 |
272 / 272 |
292 / 292 |
277 / 277 |
295 / 295 |
285 / 285 |
298 / 298 |
289 / 289 |
301 / 301 |
293 / 293 |
304 / 304 |
296 / 296 |
307 / 307 |
310 / 310 |
NOSE/TAIL LENGTH |
210 / 200 |
210 / 200 |
195 / 185 |
210 / 200 |
200 / 190 |
210 / 200 |
200 / 190 |
210 / 200 |
207.5 / 197.5 |
210 / 200 |
210 / 200 |
210 / 200 |
225 / 215 |
210 / 200 |
WAIST WIDTH |
229 |
233 |
246 |
237 |
249 |
244 |
252 |
246 |
255 |
248 |
258 |
250 |
261 |
264 |
STANCE RANGE |
440-560 |
450-570 |
440 - 560 |
450-570 |
450 - 570 |
470-590 |
450 - 570 |
490-610 |
470 - 590 |
510-630 |
520-640 |
520-640 |
520 - 640 |
550-670 |
SET BACK |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
SIDECUT RADIUS (M) |
6.7 |
6.9 |
7.6 |
7.1 |
7.7 |
7.45 |
7.8 |
7.55 |
7.9 |
8.0 |
8.0 |
8.1 |
8.1 |
8.2 |
CAMBER PROFILE
Traditional Camber
A single convex arc between the board’s contact points ensures predictable edge hold, load, and rebound as pressure is exerted and expelled throughout the rider’s turn.
WOOD CORE
MOD 3
A combination of poplar wood native to North America and high strength to weight ratio bamboo provides propulsive performance in this Core. We increased the width of the bamboo array to increase the strength and energized feel of this Core.
BASE
Premium Racing
This base utilizes a high-density, high-speed base material chosen for its molecular weight, which delivers unrivaled speed, excellent wear resistance, and increased wax permeability.
TIP TECHNOLOGY
Flexible Thin Tip
This weight-saving technology reduces material in the board’s tip and tail, resulting in lighter swing weight which makes it easier and faster to spin and rotate tricks.
FIBERGLASS LAMINATE
Tri-Tex
This is our most advanced matrix; a 3-way lay up that combines Light fiberglass at 0º, 45º, and 90º degrees, ensuring unquestionable pop, rebound, flex, and torsion in our highest performance boards.
CARBON LAY UP
Double I Carbon
Two tip-to-tail carbon stringers through the center of the core increase torsional rigidity for increased response and control.
EDGE TECHNOLOGY
Snake Bite Tech
For exceptional edge hold on ice and mixed riding conditions, this technology gets its bite from four individual contact points in the heel and toes zones, providing essential control to keep you on edge.
